You can do this from Apt on Ubuntu, as such: sudo apt-get install inkscape Obviously, it doesn’t matter what you name your plotter, or what description you give it, just give it something that makes sense. Then, select “ Raw Queue” This will work with InkCut providing the HPGL instructions. You will want to select Generic as the make of printer. If you don’t have the option for “Serial Port #1”, then use the Device URI “ serial:/dev/ttyS0“. To install this plotter in CUPS, you’ll want to open up your Printer configuration area from the System menu. This did not need to be a very secure environment (we didn’t even password protect the workstation’s desktop) so I figured this would be a reasonable approach, rather than troubleshooting why CUPS was getting permission denied errors while printing to the serial port. In order to ensure communication with non-root users, I took a questionable approach, and I decided to: chmod 777 /dev/ttyS0 I reset my plotter to the factory default settings, which resulted in a condition where I could assume this about my serial connection: In order to establish proper communications between the computer and the plotter, I had to ensure some things were true. The plotter interfaced with the computer using a serial connection. Here are some photos of the Gerber enVision plotter I was working with.
If this is not the case, I imagine most of these instructions will apply fairly well to any kind of vinyl plotter. I am also assuming you have an older Gerber enVision series plotter. However, any Ubuntu or Debian flavor should be acceptable.
On my test computer, I was working with a clean installation of Ubuntu 12.04 (12.04.1) LTS. This tutorial will assume that you have some prior experience with the Linux terminal and the Linux desktop. I am by no means an expert, but I found very limited web resources out there on this topic, and I am hopeful that someone will eventually stumble on this article and find it useful.Ī simple, free, and open source solution to an expensive and complex problem: How do we plot stuff with our vinyl plotter? This tutorial will attempt to comprehensively explain how I got this working. I decided to look into open source solutions, and I found out that Inkscape can do vinyl plotting with an extension called InkCut. I had major difficulties getting the old version of Omega working with their USB licensing stick, and I knew that getting anything like this working on Windows without proper licensing would be an inadvisable, and rocky road ahead. I recently had the opportunity to work with an older Gerber enVision plotter from a township.
